chain feed flexo printer slotter die cutter machine with stacker

chain feed flexo printer slotter die cutter machine with stacker - Welldoing trading limited

Short Description:

After-Sales Service

1. Installation, training how to use the machine and technical support.

2. Engineers available to service machinery overseas.

Send email to us Download as PDF

Product Detail

Product Tags

Semi-automatic corrguated carton printer die cutter slotter machine adopts manual feeding & automatic printing & drying mode, using eco-friendly water-based ink and flexible photopolymer plates. It features light impression printing that never collapses corrugated cardboard, widely used for cartons, paper bags & non-woven bags printing.

Advantages: Low investment cost, easy operation, eco water ink, compact structure & low failure rate, ideal for small & medium packaging factories with small-batch orders.

Disadvantages: Limited production capacity, manual color registration for multi-color printing.

semi automatic ink printing die cuttingslotting machine function and characteristics:

1. Use the combination chain style on feeding table.

2. Adopt planet style digital electrical adjustment of 360 degree whatever operating and stop quickly and accurately.

3. Ink roller can be detached automatic from printing plate to avoid damage the printing plate when stop the machine.

4. All of the shaft roller are hard chrome, strength the hardness.

5. Ink roller equipped the separately turn device to prevent ink dried when machine stop.

6. Pneumatic lock , electric divides.

7. The module design, multi-color printing units in any combination.

8. With pneumatic diaphragm pump to supply ink.

9. Main transmission gears are made by 45#steel after high frequency quenching.

Chain feeder flexo printer die cutter slotter machine Complete workflow：

The workers place the corrugated cardboard boxes on the feeding workbench and align them with the limit stop plates;
The photoelectric sensor detects that the cardboard has reached its position, triggering the equipment to automatically initiate paper feeding and ink application to the screen roller;
The flexible printing plate absorbs a predetermined amount of ink, and the impression roller applies light pressure to complete the graphic and text printing;
Upon completion of printing, immediately proceed to the drying duct to cure the ink;
Finished cardboard is shipped out, then manually picked up and stacked; this process repeats cyclically.
